Let's Build a Basic State Machine

Hello everyone, after the recent release of my state machine framework Statement (docs) (so state machines have been on my mind a lot over the last few weeks), I came to the realisation that a lot of people still have a lot of difficulty with state machines, so I decided to throw my hat in the overcrowded ring with yet another tutorial about the amazing topic of ✨State Machines✨!

The State of States

So... what is a state machine? Well, consider a player character in a platformer. They might be able to run around, maybe climb ladders, possibly swim, perhaps even fly through the sky with a power up or something. Each of those actions could be considered a state, and a state machine is the thing that handles how you move in or out of those states, and deals with the actual working of the state as well.

Why would you want to build a whole state machine just to handle some actions like that? Let me explain, my dear reader, the pains of trying to implement stuff like that without a state machine. Firstly, you have your general movement. x += hor_speed; y += ver_speed;, etc. Simple and easy, no states required. Ah, but now you want to add climbing. You do not want your character to move horizontally on the ladder, so you decide "Ok, I'll just set an is_climbing flag to true when I start to climb, and then lock the horizontal movement behind a check to make sure we are not climbing before it can run."

This seems reasonable, but it is the first dangerous step into heavy spaghetti-code territory. Next you try to add swimming, uh-oh, you'll need to add another flag to check for that, and then cancel out of the old movement completely in order to switch to the different movement for swimming (more floaty perhaps, with 360 degree motion). So you have now got three sections of code competing with each other, and being tied behind interlocking flags (what happens if you get on a ladder in the water?).

Now you add flying, and suddenly there is a whole new thing you need to check for and stuff is starting to get annoyingly complicated. Gameplay errors start creeping in (weird movement in certain situations, etc), and you are starting to bang your head on the desk wondering where it all went wrong.

This is the part of the story where the triumphant state machine walks into the room, head held high, to heroically save the day.

You see, the secret sauce behind state machines is they let you carve out little sections of code into states and then guarantee that only the code from one state is run at a time. It makes the states mutually exclusive, which then means, instead of having to try to figure out how your interlocking system of flags is leading to the player sprite incorrectly changing into swimming while you are on land, you can literally just reason about each small chunk of code at a time, safe in the knowledge that flying code will NEVER be run during swimming, no matter how hard your play-testers try to make that happen.

This might not actually sound all that amazing on the face of it, but once you start experiencing the ease of development this code partitioning allows for (and the many varied situations it can be helpful in), you will wonder how you ever did anything any other way.

Starting States

So, the preamble is out of the way, and we can begin with an implementation.

First, let me say, there are many, many ways to implement a state machine, from if... else if... else chains (ewwwww) to switch statements (slightly less ewwww but still...) to setting a state variable to different functions and running that state variable (ok, but not very flexible and has some notable shortcomings) and more.

We will be implementing my favoured method, which is to use a struct for the state machine and for each state, and having the whole thing revolve around a few simple methods called from either the state machine or the state.

So, since we will be implementing a repeated pattern of struct creation for the state machine structs, we should immediately be thinking of a constructor. Let's build a very basic one now. Create a new script, call it scr_state_machine or something and put this code in it:

function StateMachine() constructor {
    state = undefined;
}

Done and dusted. We call sm = new StateMachine(); and we have a nice little struct stored in sm with a single member variable called state. Ok, I will foreshadow that this is not going to be enough data stored yet, but we will forge on blindly ahead now. Let's create our state constructor:

function State() constructor {
    update = undefined;
}

Looking pretty good so far. Same general setup, call the constructor with new and we will get a struct with an update member variable. update will hold the code that we want the state to run each step. But we have got a few problems. Firstly, we have to directly reach into the innards of the state machine and the struct to set these fields properly, i.e.:

sm = new StateMachine();
idle = new State();
idle.update = function() {
    // Idle code here
}
// Altering state directly here feels a little icky
sm.state = idle;

While this works, it is not pretty and it is not very future-proof (what if we want to change the name of the member variable update to some other name, like run? We would have to go through our code and find every state we have created and manually edit it to the new name). Much better to create some static methods inside the constructors and assign stuff through them (otherwise known as setters, the companion of getters). We will start with the state machine and add a setter for assigning a State struct to the state variable.

function StateMachine() constructor {
    state = undefined;
    // Define a static method that we can pass the state struct to, and it does the updating. If we need to change anything about
    // how we assign a state in the future, then we only need to change this one bottleneck here, not every place in the code we change state
    static AddState = function(_state) {
        state = _state;
        return self;
    }
}

By returning self from a method, we can chain the calls together, like .AddState(_state1).AddState(_state2).AddState(_state3);. This is usually known as a "fluent" interface.

And now we do roughly the same thing for the state.

function State() constructor {
    update = undefined;
    // Another static method that allows us to provide a function the state will run every step as an argument and assign it to update.
    static SetUpdate = function(_update_func) {
        update = _update_func;
        return self;
    }
}

Ok, now we can run the methods when adding code to the state and the state to the state machine:

sm = new StateMachine();
// Now we use the new setters instead of direct assignments
idle = new State().SetUpdate(function() { /* Idle code */ });
sm.AddState(idle);

That is a bit better. But wait? How are we even going to run the state's update code? Let's add a method to the state machine to handle that:

function StateMachine() constructor {
    state = undefined;
    static AddState = function(_state) {
        state = _state;
        return self;
    }
    // We'll run this from the state machine, and it'll run the update function we stored in the state
    // (whichever state is currently assigned to the state variable).
    static Update = function() {
        // First we check to see if our state variable has been set to a struct printed out by a State constructor,
        // using is_instanceof(), so we can be sure it has the update function
        if (is_instanceof(state, State)) {
            // Then we make sure it's actually a function, since update starts off as undefined and perhaps we forgot to assign a function to it
            if (is_method(state.update)) {
                // And finally we run it.
                state.update();
            }
        }
    }
}

A Single State Problem

Ok, so now we can create a state, assign it the state machine and then run that state's code in the Step Event by running sm.Update();

Excellent. But wait a minute. What happens if we want to change states? Surely we do not want our player stuck in the idle state forever? Ok, so we cannot just use a single state variable in the state machine to hold our states. We will probably also want to name our states, so that there is a string we can read to find out what state we are currently in (maybe print it out for debugging, whatever).

We have two choices here, we can either create an array to hold all of our states, or we can create a struct to hold all our states. An array is easily loopable, and slightly faster access as long as there are not too many entries, but a struct lets us directly retrieve a specific state without having to search.

Since we will be mostly wanting to change to specific states, and will rarely want to loop over them all, I think a struct is best here, since we can use the accessor combined with a state name for easy retrieval (for example states[$ "Idle"] would retrieve whatever is stored under the "Idle" key in the states struct, which looks pretty nice to me as a way to grab a specific state), and structs are a little more human readable than arrays (less mental gymnastics in the noggin means more code done in a day).

Finally, we will want a ChangeState() method that lets us swap to another state that has been added to the state machine.

Let's get that setup.

function StateMachine() constructor {
    // We still want our state variable, as it will hold "the current state we are in"
    state = undefined;
    // But we also want a struct to store all of our states in
    states = {};

    static Update = function() {
        // First we check to see if our state variable has been set to a struct printed out by a State constructor, using is_instanceof(),
        // so we can be sure it has the update function
        if (is_instanceof(state, State)) {
            if (is_method(state.update)) {
                state.update();
            }
        }
    }
    // And we need to update our AddState so that it adds the new state to the struct, not simply setting state directly to it
    static AddState = function(_state) {
        // As a safety measure, we check to see if a state with the same name already exists in our machine.
        // If we use the accessor to access a struct, and the key doesn't exist in the struct, it returns undefined
        // So we check if it's NOT undefined, which means that the key has already been set for the states struct
        // And therefore, we've already previously added a state with that name
        if (!is_undefined(states[$ _state.name])) {
            // We could exit the function here, or overwrite the state, or whatever we decided
            // was valid behaviour. I'll just throw a debug message to console to warn the programmer
            // And then simply overwrite it
            show_debug_message($"You already have a state named {_state.name} in the state machine!");
        }
        states[$ _state.name] = _state;
        // And we check to see if state has already been assigned to a state struct. If it hasn't, then this is the first state being added
        // to the state machine, and we'll use it as the "starting" state. As a side note, this is why setters are often a good idea,
        // if we had just manually assigned state in a ton of places, and then decided to make a change like this, we'd have a major refactor on our hands,
        // but because we created a setter function early on, all we need to do is change that one function.
        if (is_undefined(state)) {
            state = _state;
        }
        return self;
    }

    // Now we make the ChangeState method
    static ChangeState = function(_name) {
        // We run the same check as in Update to see if the state exists in the states struct, and
        // if it does, we simply set state to it.
        if (!is_undefined(states[$ _name])) {
            state = states[$ _name];
        }
        // If it doesn't exist, we warn the programmer that they are trying to change to a state that
        // doesn't exist in the states struct.
        else {
            show_debug_message("Trying to change to a non-existent state!");
        }
    }
}

And we want to be able to give names to our states, so that we can use the name as the key for the states struct. Let's replace our State constructor with a version that takes a name as an argument and assigns it to a name variable:

// We give the name as a string for the argument of the State() constructor
function State(_name) constructor {
    name = _name;
    update = undefined;
    static SetUpdate = function(_update_func) {
        update = _update_func;
        return self;
    }
}

Multiple State Disorder

With all that done, we can now, finally, set up our state machine and add multiple states. Create an object (obj_player or whatever) and drop this in the Create Event:

// Set a general move speed
move_speed = 3;
// Create our state machine
sm = new StateMachine();
// Create an idle state
idle_state = new State("idle")
    // Give the idle state the code we want it to run as an anonymous function through our setter
    .SetUpdate(function() {
        // All idle checks for is whether A or D is pressed, if it is, we consider the player moving and switch to the "move" state
        if (keyboard_check(ord("A")) || keyboard_check(ord("D"))) {
            sm.ChangeState("move");
        }
    });
move_state = new State("move")
    .SetUpdate(function() {
        // Simple movement on the x axis
        var _hor = keyboard_check(ord("D")) - keyboard_check(ord("A"));
        x += _hor * move_speed;
        if (_hor == 0) {
            sm.ChangeState("idle");
        }
    });
sm.AddState(idle_state).AddState(move_state);

Now we need to actually run the state machine in the Step Event:

sm.Update();

And finally, we will add a little bit of drawing so we can actually see the player and the state's name into the Draw Event:

draw_set_color(c_green);
draw_circle(x, y, 32, false);
draw_set_color(c_yellow);
draw_set_halign(fa_center);
draw_set_valign(fa_bottom);
draw_text(x, y - 32, sm.state.name);

Make sure you have your object added to your room, run your game, and you should be able to run back and forth, and see the state text above its head change as you switch from moving to standing still. And that is that. We have built a rudimentary state machine. There are many, many ways we could extend it. For instance, keeping track of the last state it was in prior to the current one (or even adding a whole state history to help with debugging). Perhaps we want to be able to run code when a state is entered? Or exited? Or maybe we want to be able to queue state changes? The world is your oyster when it comes to ways you can extend state machines to be more useful. At its core though, they all boil down to the same thing: separating code into buckets, and making sure only one bucket of code runs at a single time.

All that being said, you do not need to develop all this stuff because I have already done it for you (yes it is another plug)! Check out Statement if you are curious to see what a fully featured state machine framework looks like.

Now I think it is time for me to head back into my lair for a bit, but this time, I will not be gone long. There are things brewing and plans afoot that are coming to fruition soon. Be sure to check back regularly to see what they might be (I feel like I have to check my Pulse *ahem* after all this excitement).

If you end up using the tutorial or Statement, a rating or comment on itch helps a lot :D

Oh, and here's a downloadable project with all the code in it if you are having difficulty or just want to see it in action.

Catch you on the flipside my peeps.
